Web API CRUD Operations in Angular 7

Create Table in Database

Visual Studio 2017

                File

                New

                Project

                Select Web

                                Choose ASP.NET Web Application(.NET Framework)

                Project Name : WebAPI  after select location  project folder

Ok

Click on Add button

Click on next Button

Click on Ok Button

Then click on Finish Button

Created Web API

Folder Name: Models --- > DBModels.edmx  --- >  DBModels.tt --- >  Employee.cs

//------------------------------------------------------------------------------

// <auto-generated>

//     This code was generated from a template.

//

//     Manual changes to this file may cause unexpected behavior in your application.

//     Manual changes to this file will be overwritten if the code is regenerated.

// </auto-generated>

//------------------------------------------------------------------------------

namespace WebAPI.Models

{

    using System;

    using System.Collections.Generic;



    public partial class Employee

    {

        public int EmployeeID { get; set; }

        public string FullName { get; set; }

        public string EMPCode { get; set; }

        public string Mobile { get; set; }

        public string Position { get; set; }

    }

}

Rebuild solution

Controllers Folder right click

EmployeesController.cs in Controllers

using System;

using System.Collections.Generic;

using System.Data;

using System.Data.Entity;

using System.Data.Entity.Infrastructure;

using System.Linq;

using System.Net;

using System.Net.Http;

using System.Web.Http;

using System.Web.Http.Description;

using WebAPI.Models;

namespace WebAPI.Controllers

{

    public class EmployeesController : ApiController

    {

        private DBModel db = new DBModel();

        // GET: api/Employees

        [HttpGet]

        [Route("API/GetEmployees")]

        public IQueryable<Employee> GetEmployees()

        {

            return db.Employees;

        }

        // PUT: api/Employees/5

        [HttpPut]

        [Route("API/PutEmployee")]

        [ResponseType(typeof(void))]

        public IHttpActionResult PutEmployee(Employee employee)

        {

            if (employee.EmployeeID ==0)

            {

                return BadRequest();

            }

            db.Entry(employee).State = EntityState.Modified;

            try

            {

                db.SaveChanges();

            }

            catch (DbUpdateConcurrencyException)

            {

                if (!EmployeeExists(employee.EmployeeID))

                {

                    return NotFound();

                }

                else

                {

                    throw;

                }

            }

            return StatusCode(HttpStatusCode.NoContent);

        }

        // POST: api/PostEmployee

        [HttpPost]

        [Route("API/PostEmployee")]

        [ResponseType(typeof(Employee))]

        public IHttpActionResult PostEmployee(Employee employee)

         {

            db.Employees.Add(employee);

            db.SaveChanges();

           // return CreatedAtRoute("DefaultApi", new { id = employee.EmployeeID }, employee);

            return StatusCode(HttpStatusCode.OK, employee);

        }

        // DELETE: api/Employees/5

        [HttpGet]

        [Route("API/DeleteEmployee")]

        [ResponseType(typeof(Employee))]

        public IHttpActionResult DeleteEmployee(int id)

        {

            Employee employee = db.Employees.Find(id);

            if (employee == null)

            {

                return NotFound();

            }

            db.Employees.Remove(employee);

            db.SaveChanges();

            return Ok(employee);

        }

        protected override void Dispose(bool disposing)

        {

            if (disposing)

            {

                db.Dispose();

            }

            base.Dispose(disposing);

        }

        private bool EmployeeExists(int id)

        {

            return db.Employees.Count(e => e.EmployeeID == id) > 0;

        }

    }

}

******************************  WebAPI Part is Completed  ******************************

Next automatically install Microsoft.AspNet.WebApi.Cors

After install solution then WebAPI Project build solution

Code

using System;

using System.Collections.Generic;

using System.Linq;

using System.Web.Http;

using System.Web.Http.Cors;

namespace WebAPI

{

    public static class WebApiConfig

    {

        private static string headers;

        private static string methods;

        public static void Register(HttpConfiguration config)

        {

            //Enable CORs

            config.EnableCors(new EnableCorsAttribute("*", headers = "*", methods = "*"));

            // Web API configuration and services

            // Web API routes

            config.MapHttpAttributeRoutes();

            config.Routes.MapHttpRoute(

                name: "DefaultApi",

                routeTemplate: "api/{action}/{id}",

                defaults: new { id = RouteParameter.Optional }

            );

        }

    }

}

 -----------------------------------------------------------------------------

Create Angular Project create

Visual Studio Code

Open Created webAPI folder select folder

ng new Angular7

cd Angular7

ng serve --open

Angular7 Project structure

Created all folders

angular.json

{ "$schema": "./node_modules/@angular/cli/lib/config/schema.json", "version": 1, "newProjectRoot": "projects", "projects": { "Angular7": { "root": "", "sourceRoot": "src", "projectType": "application", "prefix": "app", "schematics": {}, "architect": { "build": { "builder": "@angular-devkit/build-angular:browser", "options": { "outputPath": "dist/Angular7", "index": "src/index.html", "main": "src/main.ts", "polyfills": "src/polyfills.ts", "tsConfig": "src/tsconfig.app.json", "assets": [ "src/favicon.ico", "src/assets" ], "styles": [ "src/styles.css", "node_modules/ngx-toastr/toastr.css" ], "scripts": [] }, "configurations": { "production": { "fileReplacements": [ { "replace": "src/environments/environment.ts", "with": "src/environments/environment.prod.ts" }], "optimization": true, "outputHashing": "all", "sourceMap": false, "extractCss": true, "namedChunks": false, "aot": true, "extractLicenses": true, "vendorChunk": false, "buildOptimizer": true, "budgets": [ { "type": "initial", "maximumWarning": "2mb", "maximumError": "5mb" } ] } } }, "serve": { "builder": "@angular-devkit/build-angular:dev-server", "options": { "browserTarget": "Angular7:build" }, "configurations": { "production": { "browserTarget": "Angular7:build:production" } }}, "extract-i18n": { "builder": "@angular-devkit/build-angular:extract-i18n", "options": { "browserTarget": "Angular7:build" }}, "test": { "builder": "@angular-devkit/build-angular:karma", "options": { "main": "src/test.ts", "polyfills": "src/polyfills.ts", "tsConfig": "src/tsconfig.spec.json", "karmaConfig": "src/karma.conf.js", "styles": [ "src/styles.css" ], "scripts": [], "assets": [ "src/favicon.ico", "src/assets"
] } }, "lint": { "builder": "@angular-devkit/build-angular:tslint", "options": { "tsConfig": [ "src/tsconfig.app.json", "src/tsconfig.spec.json" ], "exclude": [ "**/node_modules/**" ] }} }}, "Angular7-e2e": { "root": "e2e/", "projectType": "application", "prefix": "", "architect": { "e2e": { "builder": "@angular-devkit/build-angular:protractor", "options": { "protractorConfig": "e2e/protractor.conf.js", "devServerTarget": "Angular7:serve" }, "configurations": { "production": { "devServerTarget": "Angular7:serve:production" } }}, "lint": { "builder": "@angular-devkit/build-angular:tslint", "options": { "tsConfig": "e2e/tsconfig.e2e.json", "exclude": [ "**/node_modules/**" ]

}} }} }, "defaultProject": "Angular7" }

index.html

<!doctype html> <html lang="en"> <head> <meta charset="utf-8"> <title>Angular7</title> <base href="/"> <meta name="viewport" content="width=device-width, initial-scale=1"> <link rel="icon" type="image/x-icon" href="favicon.ico"> <link rel="stylesheet" href="https://stackpath.bootstrapcdn.com/bootstrap/4.3.1/css/bootstrap.min.css" integrity="sha384-ggOyR0iXCbMQv3Xipma34MD+dH/1fQ784/j6cY/iJTQUOhcWr7x9JvoRxT2MZw1T" crossorigin="anonymous"> </head> <body>

<app-root></app-root> <script src="https://code.jquery.com/jquery-3.3.1.slim.min.js" integrity="sha384-q8i/X+965DzO0rT7abK41JStQIAqVgRVzpbzo5smXKp4YfRvH+8abtTE1Pi6jizo" crossorigin="anonymous"></script> <!-- <script src="https://cdnjs.cloudflare.com/ajax/libs/popper.js/1.14.7/umd/popper.min.js" integrity="sha384-UO2eT0CpHqdSJQ6hJty5KVphtPhzWj9WO1clHTMGa3JDZwrnQq4sF86dIHNDz0W1" crossorigin="anonymous"></script> --> <script src="https://stackpath.bootstrapcdn.com/bootstrap/4.3.1/js/bootstrap.min.js" integrity="sha384-JjSmVgyd0p3pXB1rRibZUAYoIIy6OrQ6VrjIEaFf/nJGzIxFDsf4x0xIM+B07jRM" crossorigin="anonymous"></script> </body> </html>

app.module.ts

import { BrowserModule } from '@angular/platform-browser'; import { NgModule } from '@angular/core'; import { FormsModule } from '@angular/forms'; import { BrowserAnimationsModule } from '@angular/platform-browser/animations'; // import { ToastrModule } from 'ngx-toastr'; import { AppComponent } from './app.component'; import { EmployeesComponent } from './employees/employees.component'; import { EmployeeComponent } from './employees/employee/employee.component'; import { EmployeeListComponent } from './employees/employee-list/employee-list.component'; import { EmployeeService } from './shared/employee.service'; import { HttpClientModule } from '@angular/common/http'; @NgModule({ declarations: [ AppComponent, EmployeesComponent, EmployeeComponent, EmployeeListComponent ], imports: [ BrowserModule, FormsModule, HttpClientModule, BrowserAnimationsModule, // ToastrModule ], providers: [EmployeeService], bootstrap: [AppComponent] }) export class AppModule { }

app.component.ts

<div class="col-md-12"> <app-employees></app-employees> </div>

employees ---> employees.component.html

<div class="jumbston"> <h3 class="display-6 text-center"> Employee Register </h3> <hr> <div class="row"> <div class="col-md-4"> <app-employee></app-employee> </div> <div class="col-md-8"> <app-employee-list></app-employee-list> </div> </div> </div>

employees ---> employees.component.ts

import { Component, OnInit } from '@angular/core'; @Component({ selector: 'app-employees', templateUrl: './employees.component.html', styleUrls: ['./employees.component.css'] }) export class EmployeesComponent implements OnInit { constructor() { } ngOnInit() {} }

employees ---> employee --->  employee.component.html

<form #form="ngForm" (submit)="onSubmit(form)" autocomplete="off">

<input type="hidden" name="EmployeeID" #EmployeeID="ngModel" [(ngModel)]="service.formData.EmployeeID"> <div class="form-group"> <label for="">Full Name</label> <input name="FullName" #FullName="ngModel" [(ngModel)]="service.formData.FullName" class="form-control" placeholder="Full Name" required> <div class="validation-error" *ngIf="FullName.invalid && FullName.touched">
This field is required</div> </div> <div class="form-group"> <label for="">Position</label> <input name="Position" #Position="ngModel" [(ngModel)]="service.formData.Position" class="form-control" placeholder="Position" required> </div>

<div class="row"> <div class="form-group col-md-6"> <label for="">EMP Code</label> <input name="EMPCode" #EMPCode="ngModel" [(ngModel)]="service.formData.EMPCode" class="form-control" placeholder="EMP Code" required> </div> <div class="form-group col-md-6"> <label for="">Mobile</label> <input name="Mobile" #FullName="ngModel" [(ngModel)]="service.formData.Mobile" class="form-control" placeholder="Mobile" required> </div> </div> <div> <button type="submit" [disabled]="form.invalid" class="btn btn-lg btn-info btn-block">Submit</button> </div> </form>

employees ---> employee --->  employee.component.ts

import { Component, OnInit } from '@angular/core'; import { EmployeeService } from 'src/app/shared/employee.service'; import { NgForm } from '../../../../node_modules/@angular/forms'; // import { ToastrService} from 'ngx-toastr'; @Component({ selector: 'app-employee', templateUrl: './employee.component.html', styleUrls: ['./employee.component.css'] }) export class EmployeeComponent implements OnInit { constructor(private service: EmployeeService, // private toastr : ToastrService ) { } ngOnInit() { this.restForm(); } restForm(form?: NgForm) { if (form != null) form.resetForm(); this.service.formData = { EmployeeID: null, FullName: '', Position: '', EMPCode: '', Mobile: '', } } onSubmit(form:NgForm){ debugger; if(form.value.EmployeeID == null) this.insertRecord(form) else this.updateRecord(form); } insertRecord(form:NgForm){ this.service.postEmployee(form.value).subscribe(res =>{ // this.toastr.success('Insert Successfully', 'EMP. Register'); this.restForm(form); this.service.refreshList(); }); } updateRecord(form:NgForm){ this.service.putEmployee(form.value).subscribe(res =>{ // this.toastr.warning('Updated Successfully', 'EMP. Register'); this.restForm(form); this.service.refreshList(); }); } deleteRecord(form:NgForm){ this.service.deleteEmployee(form.value).subscribe(res =>{ // this.toastr.warning('Updated Successfully', 'EMP. Register'); this.restForm(form); this.service.refreshList(); }); } }

employees ---> employee --->  employee-list.component.html

<table class="table table-bordered table-hover"> <tr *ngFor="let emp of service.list"> <td (click)="populateForm(emp)">[{{emp.EMPCode}}] - {{emp.FullName}} </td> <td (click)="populateForm(emp)">{{emp.FullName}}</td> <td (click)="populateForm(emp)">{{emp.Position}}</td> <td (click)="populateForm(emp)">{{emp.Mobile}}</td> <td><button (click)="onDelete(emp.EmployeeID)" class="btn btn-danger btn-sm">X</button></td> </tr> </table>

employees ---> employee --->  employee-list.component.ts

import { Component, OnInit } from '@angular/core'; import { EmployeeService } from '../../shared/employee.service'; import { Employee } from '../../shared/employee.model'; @Component({ selector: 'app-employee-list', templateUrl: './employee-list.component.html', styleUrls: ['./employee-list.component.css'] }) export class EmployeeListComponent implements OnInit { constructor(private service : EmployeeService, //private toatr:ToastrService ) { } ngOnInit() { this.service.refreshList(); } populateForm(emp:Employee){ this.service.formData=Object.assign({}, emp); } onDelete(id:number){ this.service.deleteEmployee(id).subscribe(res=>{ this.service.refreshList(); // this.toastr.warning('Delete Successfully', 'EMP. Register'); }) } }

shared---> employee.models.ts

export class Employee { EmployeeID:number; FullName:string; EMPCode:string; Mobile:string; Position:string; }

shared---> employee.service.ts

import { Injectable } from '@angular/core'; import { Employee } from './employee.model'; import { HttpClient } from '@angular/common/http'; // import { ToastrService} from 'ngx-toastr'; @Injectable({ providedIn: 'root' }) export class EmployeeService { formData: Employee; list: Employee[]; readonly rootURL = "http://localhost:51757/api"; constructor(private http: HttpClient) { } // constructor(private http: HttpClient, // private toastr : ToastrService) { } postEmployee(formData: Employee) { return this.http.post(this.rootURL + '/PostEmployee', formData); //this.refreshList(); } refreshList() { //debugger; this.http.get(this.rootURL + '/GetEmployees') .toPromise().then(res => this.list = res as Employee[]) } putEmployee(formData: Employee) { //debugger; return this.http.put(this.rootURL + '/PutEmployee', formData); // this.refreshList(); } deleteEmployee(id: number) { if (confirm('Are you want to delete this record?')) return this.http.get(this.rootURL + '/DeleteEmployee?id='+id); // this.refreshList(); // this.toastr.info('Delete Successsfully', 'EMP. Register'); } }

shared---> employee.service.spec.ts

import { TestBed } from '@angular/core/testing'; import { EmployeeService } from './employee.service'; describe('EmployeeService', () => { beforeEach(() => TestBed.configureTestingModule({})); it('should be created', () => { const service: EmployeeService = TestBed.get(EmployeeService); expect(service).toBeTruthy(); }); });

OUTPUT
